Major Specification

Shuttle speed　: 120-150 RPM

Nos. of shuttle 　: 6 SETS

Weft density 　: 7-16 P/IN

Lay flat width 　: 400-900 MM

Weft tube 　: 23-38 MM

Maximum weft package 　: 110 MM

Warp tube 　: 23.30.35.38 MM

Maximum diameter of web-roll 　: 1000 MM

Torque motor 　: 10 KG-CM

Main motor 　: 5 HP

Fan motor 　: 1/2 HP

Inverter 　: 5 HP

Net Weight 　: 2,500 KGS

Gross Weight 　: 2,800 KGS
